AG2-SV14-B Air Compressor / Generator for Mobile Crew Air + Electric Power
Choose this gasoline air compressor and generator combination for unmatched performance, supplying air power and electricity to any jobsite. Facility managers and contractors specify the AG2-SV14-B when uptime and serviceability matter more than entry-price tags.
AG2-SV14-B Tank, Pump, and Power Configuration
Specifications cover the rated CFM, tank volume, and motor configuration that determine which tools and stations the AG2-SV14-B supports.
- Compressor Pump — Cast iron compressor pump · Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator
- Generator — Brushless alternator · Total harmonic distortion (THD) less than 6% · 100% copper windings · (2) NEMA 5-20R 120V, 20A and (1) NEMA L6-20R 240V, 20A receptacles
- Chassis — 3/16-inch base plate to reduce vibration · Powder coated two-piece belt guard. Reduces operator fatigue on long jobs and survives bouncing in service trucks.
- Components — Regulator and two gauges for tank and outlet pressure · 150-PSI maximum rated regulator · Manual drain valves for proper maintenance · 12 or 16½-inch fly wheel · Quality pilot valve unloader Note: All gasoline models sold in California are required to have a CARB compliant engine. Consult factory. 49 state engine. Not for sale in California. Receiver tank required.
- Warranty — 2 Year Alternator · 2 Year Pump Exchange · 3 Year Vanguard Engine. Factory-backed coverage on the wear components facility crews replace first.
AG2-SV14-B Applications and Environments
The AG2-SV14-B pairs air and electrical output on one chassis for mobile crews: HVAC service vans, construction-site framing, tire and lube trucks, agricultural maintenance, and remote project staging where running a separate generator and compressor doubles fuel logistics. Service businesses cut truck-bed space and trailer-pull weight by consolidating to a single combo unit.
AG2-SV14-B Pump Build and Duty Cycle
OEM motor drives the pump via belt drive configuration; cast-iron cylinder construction matches the duty cycle expected in commercial shops. Service intervals follow the pump-oil schedule in the operator manual. NEMA plug configuration on electric variants determines circuit-breaker sizing — verify against the facility panel before specifying.
Specifications
| CFM @ PSI | 15.7 @ 175 |
| Alternator Wattage: Max. Output | 4000 watts |
| Alternator Wattage: Cont. with Comp. On-Load | 2300 watts |
| Alternator Wattage: Cont. with Comp. Off-Load | 3500 watts |
| Displacement/ Engine | 408cc Vanguard OHV |
| Net Weight | 325.00 lbs. |
| Shipping Weight | 390.00 lbs. |
| Length | 47.00 in. |
| Width | 22.00 in. |
| Height | 28.00 in. |
