Ebac DD300 Desiccant Dehumidifier
The Ebac DD300 Desiccant Dehumidifier is a compact, rugged, and lightweight drying solution designed for applications that require extremely low humidity levels, even in sub-zero temperatures. With its high-grade stainless steel construction, PTC heater for rapid and consistent drying, and washable high-performance silica gel rotor, the DD300 delivers unmatched performance in demanding environments. Perfect for industrial, commercial, and restoration work where maintaining humidity below 45% RH is crucial.
Why You’ll Love the Ebac DD300 Desiccant Dehumidifier
- Operates effectively down to -4°F
- Compact & lightweight for easy transport
- Maintains low relative humidity below 45%
- High-grade stainless steel build for durability
- Quick setup with spigot connectors
- Powerful PTC heating element for rapid drying
Perfect For:
- Industrial and commercial drying applications
- Cold storage facilities
- Flood and water damage restoration
- Military and marine environments
- Any area requiring low dew point control
Key Features and Benefits
- Stainless Steel Construction – Rust-free and built for harsh environments
- Auto / Manual Mode Selection – Flexible operation for any job
- Electronic Controls – Easy monitoring and precision control
- High Capacity PTC Heater – Ensures consistent, rapid drying
- Remote Humidistat Facility – Optional automatic operation
- Ammeter & Hours Run Meter – Monitor performance and run time
- Low Temperature Operation – Ideal for cold, damp conditions
- Washable PPS Rotor – High efficiency, long life silica gel wheel
Specifications
| Model No. | 10501SS-US |
| Height | 14.5″ (370 mm) |
| Width | 14.2″ (360 mm) |
| Depth | 17″ (430 mm) |
| Weight | 44 lbs (20 kg) |
| Voltage | 110V |
| Current | 12.4 A |
| Phase | 1 |
| Frequency | 60 Hz |
| Power | 1.4 kW |
| Process Airflow – Dry Air | 136 cfm (231 m³/hr) |
| Regen Airflow – Wet Air | 42 cfm (71 m³/hr) |
| Process Duct Size – Dry Air | 5″ (130 mm) |
| Regen Duct Size – Wet Air | 2.75″ (70 mm) |
| Rotor Wheel Speed | 20 rph |
| Noise Level | 67 dba |
| Typical Extraction @ 27°C 60% | 69 ppd (32.6 lt/day) |
| Min Operating Temperature | -4°F (-20°C) |
| Max Operating Temperature | 104°F (40°C) |
Documents
Spec Sheet
Manual
DD300 Wiring Diagram (PDF)
DD300 Wiring Schematic (PDF)
