ACOPOWER 200 Watts Mono Solar Panel, HY200-12MB
The 200W 12V Monocrystalline Solar Panel (HY200-12MB) is designed to deliver reliable and efficient power generation for off-grid and mobile energy systems. Built with high-efficiency monocrystalline solar cells, it provides strong performance even in low-light conditions, making it a dependable solution for a wide range of applications.
Its durable aluminum frame and weather-resistant construction ensure long-term outdoor use. This panel is ideal for RVs, boats, cabins, remote installations, and backup power systems where stable solar energy is required.
Technical Specifications
| Feature | Specification |
|---|---|
| Maximum Power (Pmax) | 200W |
| Nominal Voltage | 12V |
| Cell Type | Monocrystalline (high efficiency) |
| Open-Circuit Voltage (Voc) | ≈ 22.1V |
| Optimum Operating Voltage (Vmp) | ≈ 18.7V |
| Short-Circuit Current (Isc) | ≈ 11.3A |
| Operating Current at Max Power (Imp) | ≈ 10.7A |
| Cell Efficiency | ~23% |
| Maximum System Voltage | 600V DC |
| Junction Box Rating | IP65 (weather-resistant) |
| Operating Temperature Range | -40°C to +85°C |
| Dimensions | ≈ 1496 × 705 × 35 mm |
| Weight | ≈ 11.2 kg |
| Output Cable | Pre-installed 12 AWG cable |
